Android Ripples With Rounded Corners

| Comments

So recently I was trying to add a ripple to a view that had rounded corners. Simple enough right? Let’s just say I have a FrameLayout with the background similar to this one:

1
2
3
4
5
6
7
8
9
<?xml version="1.0" encoding="utf-8"?>
<shape xmlns:android="http://schemas.android.com/apk/res/android"
    android:shape="rectangle">
    <solid android:color="@android:color/transparent"/>
    <corners android:radius="15dp" />
    <stroke
        android:width="1px"
        android:color="#000000" />
</shape>

It’s not quite as simple as setting the foreground to ?attr/selectableItemBackground, or else you’ll see the ripple surpasses the corners (which doesn’t look so bad when your border radius is small, but this would look terrible with a circlular view):

The solution for this lies in the special mask layer of the RippleDrawable. You specify the mask layer via the android:id value set to @android:id/mask. For the example above, you can set the mask to the same size/shape as the view you’re masking, and then the ripple will only show for that area. For something like our example above, you’d use something like this:

1
2
3
4
5
6
7
8
9
10
11
<?xml version="1.0" encoding="utf-8"?>
<ripple xmlns:android="http://schemas.android.com/apk/res/android"
    android:color="?android:attr/colorControlHighlight">
    <item android:id="@android:id/mask">
        <shape android:shape="rectangle">
            <solid android:color="#000000" />
            <corners android:radius="15dp" />
        </shape>
    </item>
    <item android:drawable="@drawable/rounded_corners" />
</ripple>

Now when you tap on the view, you’ll see something like this:

Huzzah!

Another tip: if you don’t set a click listener for a FrameLayout (like we used in this example), the pressed state will never be used!

Blurred Background Effect for Android

| Comments

A few months ago, the Android design team reviewed apps that they thought were good-looking, and were referred to as the “Beautiful Design Collection”, as part of their Android Design in Action series.

One of these apps was Etsy, which had a very cool fading blur background effect, which you can see here:

As a learning experiment, I set off to replicate this behavior. I had seen a library by Manuel Peinado called GlassActionBar which demonstrated a similar glass-like blur effect on the ActionBar, so I decided to use that code for blurring my background.

The code itself is pretty interesting, specifically the bit for versions on Jelly Bean or higher. If you’re using API version 16 and up, you can use Renderscript Intrinsics, which are a set of built-in functions that require very little code to use, but are optimized for high-performance.

In my sample tests, using Renderscript to blur the image took on average about ~175ms, vs ~2 seconds doing the blur using Java code. (The required code is also only a tiny fraction of the length of the Renderscript one).

Renderscript is extremely easy to add to your project, just throw

1
2
    renderscriptTargetApi 19
    renderscriptSupportMode true

in your build.gradle and you should be ready to roll.

Once you have the blurring, the rest of the process is fairly straight forward. When you plan to leave an activity, create a bitmap of the current view and write it to disk. When you start your new activity (which should have a transparent background), you override the transition (otherwise you’ll get the default zoom), and set the background to the blurred image you saved earlier. Add a fade in for the alpha and you get a nice little effect!

If you’d like to see how this looks in a sample project, you can find it on Github here.

Building OBS Studio for OS X

| Comments

Recently I’ve been watching a bunch of streams on Twitch, and was investigating the best options to stream from OS X. Sadly most of the ones I found were very expensive, until I saw that Open Broadcaster Software, which was previously only for Windows, was being rewritten to work with OS X and Linux. However, it’s still highly beta/under development and as a result, there’s not a lot of documentation on how to build it.

Here’s how I did it:

1
2
3
4
5
6
7
brew install ffmpeg glew cmake qt5
git clone https://github.com/jp9000/obs-studio.git
cd obs-studio
mkdir cmbuild && cd cmbuild
export CMAKE_PREFIX_PATH=/usr/local/Cellar/qt5/5.2.1/lib/cmake
cmake .. && make
cpack

This will leave you with a disk image named obs-studio-x64-<sha1-hash>.dmg, which you can mount and install, just like any other OS X application.

Happy Streaming!

Embedding Google+ Posts in Octopress

| Comments

A few months back I wrote a blog post about my 2013 in Review. One thing I wanted to add to the post was a link to the #AutoAwesomed video, which was generated from photos and videos I took during the year, which were backed up to Google+.

Fortunately for me, Google allows you to embed posts into your pages using a technique which is documented here. The problem with this method, for me at least, is that my blog is created using Octopress, and posts are written in Markdown and then rendered to HTML. Octopress does, however, allow you to write plugins which can help us with this issue.

Here’s the plugin in all it’s glory:

ADB Over WiFi

| Comments

I haven’t updated my blog in a while, but this is a tip/trick that’s so good that I had to share. It’s not a very widely known feature, but once you try it, you’ll wonder how you lived with out it: using ADB over WiFi! That’s right, no more plugging in all your devices to your computer to debug/etc. Best of all, no root required.

It’s also ingeniusly simple. First, connect the device you want to use via a USB cable.

1
2
3
adb tcpip 5555
(Feel free to unplug it now)
adb connect <IP address of your device>

That’s it! Enjoy your tether-free development.

2013 in Review

| Comments

Today is December 31st, and I decided to write up a blog post, reflecting on the year that I’ve had. I’ve learned a lot over the last twelve months, and done a lot of interesting things (okay, at least interesting to me). Here’s a brief overview of what happened:

Using a ViewPager in a ScrollView

| Comments

For a new app that I’m working on, I wanted to use a ViewPager inside a ScrollView in order to make a simple image carousel. The only problem is, ScrollViews don’t seem to play nicely with horizontally swiping Views. As soon as the user moves their finger even slightly up or down, the ViewPager page change is cancelled, and the page snaps back to the current item. This can lead to an extremely frustrating user experience, because it is difficult for the user to understand why the views won’t swipe.

My Newest App: Bike Finder

| Comments

Last week I released my newest Android app, Bike Finder. It’s a fairly straight forward application that allows you to find bikes and stations for use with Washington DC’s Capital Bikeshare system. For those of you not local to DC, Capital Bikeshare is a system that lets you use bikes that are available at docking stations all over the city, as well as parts of northern Virginia. The app is free, and I’m looking into adding additional cities that have companies that make their bike sharing data available (currently investigating New York City, Montreal and the Bay Area). If you’d like to get your city added, let me know, and I’ll see if the data is available, and add it to the to-do list.
